John Deere 4075R Heavy Duty Compact Utility Tractor

Description

Flagship of the 4 Series. 75 HP Yanmar Diesel. Serious Work Capacity.

The John Deere 4075R is the flagship of the 4 Series compact utility tractor lineup, engineered for large-property owners, small farms, and commercial operations that need serious loader work, hay handling, snow clearing, and heavy ground-engaging capability. With a 75 HP Yanmar diesel, a heavy-duty front axle, and a standard factory cab with heat and A/C, it delivers the muscle of an agricultural tractor in a compact-tractor footprint.

Power comes from a Yanmar 4TNV86CHT-MJT 4-cylinder turbocharged diesel (2.091 L / 127.6 cu in.) rated at 75 HP with approximately 60 PTO HP, delivering strong torque reserve for heavy loads. The three-range eHydro™ transmission with Twin Touch™ foot pedals includes eThrottle™, SpeedMatch™, LoadMatch™, MotionMatch, and automotive-style cruise control – all standard.

The electro-hydraulic 3-point hitch allows cab-based depth adjustment and precise, repeatable implement control. Hitch Assist™ lets a single operator back up to and connect implements without a helper. Lift capacity is 2,709 lb behind the link arms, and a CAN connection with 30 amps at the rear supports electronically controlled implements.

Specifications

• Engine: Yanmar 4TNV86CHT-MJT, 4-cylinder turbo diesel, 2.091 L (127.6 cu in.), 75 HP

• PTO: ~60 HP, Category 1/2 three-point hitch

• Transmission: 3-range eHydro™ with Twin Touch™ pedals

• Drive: 4WD standard

• Lift Capacity (24 in. behind link arms): 2,709 lb (1,229 kg)

• Fuel Capacity: 14.7 U.S. gal. (55.58 L)

• Wheelbase: 73 in. (1,850 mm)

• Front Axle Clearance: 13.8 in.

• Approximate Weight: 4,675 lb

• Bore & Stroke: 3.4 x 3.54 in. (86 x 90 mm)

Features

• Standard factory cab with heat and A/C, deluxe and snow cab configurations available

• Standard air-ride seat on Cab Tractor with fore-aft slide, reclining back

• Electro-hydraulic 3-point hitch with cab-based control

• Hitch Assist™ for one-person implement connection

• Hydrostatic power steering

• Operator presence system (tractor stops when operator leaves seat)

• LED headlights for enhanced low-light visibility

• Bluetooth®-ready radio in cab

• Two roof-mounted adjustable halogen work lights (Deluxe/Snow cab)

• CAN connection with 30 amps at rear for electronic implements

• Rust- and dent-resistant hood

• Compatible with front loaders, rotary cutters, box blades, pallet forks, tillers, snow implements, and more

• 6-year / 2,000-hour powertrain warranty

• Assembled in Augusta, Georgia, USA
